Manipulating Door Locks through Pen Springs: A Guide to Unauthorized Access
In the heart of an 1890s house, a modern innovation has been born - a custom door lock position sensor. This ingenious device, created by Nathan, repurposes common components such as springs from a ballpoint pen and a BeagleBone Black, to solve a unique challenge in automating an old basement deadbolt.
The mechanical heart of the sensor lies in the springs, which act as compliant electrical contacts mounted on the door frame. These springs touch the metal deadbolt when it is locked, creating a switch whose state changes with the lock position. The springs compensate for slight misalignment or movement by compressing, preventing the sensor from being overly sensitive to exact positioning.
The electrical connection to the BeagleBone Black's GPIO (General Purpose Input/Output) pin is straightforward. The springs are wired to this pin, and the deadbolt closing the gap completes the circuit. The GPIO can be configured with a pull-up resistor and reads the analog or digital state (depending on wiring) to detect the lock state.
To combat high-frequency noise, an RC filter is incorporated close to the sensor. This filter uses a resistor in series and a capacitor to ground, forming a simple circuit that smooths out transient spikes by limiting the bandwidth of the signal. Typical values could be a 10 kΩ resistor and a 0.1 µF capacitor, but these depend on the noise environment and response time requirements.
Due to the sensor wiring running over a long distance (often >15 ft), it picks up high-frequency noise. The RC filter reduces this electrical noise before the signal reaches the BeagleBone.
To handle the mechanical springs' inherent noise and contact bounce, software debouncing is implemented in the sensor reading routine. This reduces false triggering due to contact bounce, ensuring reliable detection of the lock state.
In summary, the core components of Nathan's sensor include pen spring contacts, an RC low-pass filter, the BeagleBone Black's GPIO, and software debouncing code. This approach enables reliable detection of the door lock's position in a vintage house with challenging sensor placement and noisy, long wiring runs by combining mechanical ingenuity with analog filtering and robust software debouncing.
This project is a testament to the versatility of repurposing components in various projects, and it overcomes the challenges posed by automating an old house that is not conducive to using off-the-shelf home automation devices.
[1] RC filter design for noise reduction in sensor applications. (n.d.). Retrieved from https://www.electronics-tutorials.ws/filter/filter_3.html [2] Debouncing techniques for digital switches. (n.d.). Retrieved from https://www.electronics-tutorials.ws/io/io_1/io_16.html [3] BeagleBone Black GPIO pin configuration. (n.d.). Retrieved from https://beagleboard.org/static/docs/bone/io-expander/p9-pinout.pdf
